Events

1
eventSystem.subscribe("@itential/app-workflow_engine", "jobStart", jobStartHandler);

1
{
2
  type: <number>,
3
  source: '@itential/app-workflow_engine',
4
  topic: '<event_topic>',
5
  instance: 'WorkFlowEngine',
6
  timestamp: <timestamp_in_milliseconds>,
7
  payload: {
8
    job: {
9
      // Complete job document from MongoDB
10
      _id: '<job_id>',
11
      name: '<job_name>',
12
      tasks: { /* task definitions */ },
13
      status: '<job_status>',
14
      // Additional job properties...
15
    }
16
  }
17
}

1
const util = require('util');
2
3
const inspect = msg => {
4
  console.log(util.inspect(msg, false, null, true));
5
}
6
7
// Subscribe to job lifecycle events
8
eventSystem.subscribe('@itential/app-workflow_engine', 'jobStart', inspect);
9
eventSystem.subscribe('@itential/app-workflow_engine', 'jobComplete', inspect);
10
eventSystem.subscribe('@itential/app-workflow_engine', 'jobError', inspect);
11
eventSystem.subscribe('@itential/app-workflow_engine', 'jobFix', inspect);
12
eventSystem.subscribe('@itential/app-workflow_engine', 'jobPause', inspect);
13
eventSystem.subscribe('@itential/app-workflow_engine', 'jobResume', inspect);
14
eventSystem.subscribe('@itential/app-workflow_engine', 'jobCancel', inspect);
15
eventSystem.subscribe('@itential/app-workflow_engine', 'jobSlaBreach', inspect);

1
{
2
  type: 16,
3
  source: '@itential/app-workflow_engine',
4
  topic: 'jobSlaBreach',
5
  instance: 'WorkFlowEngine',
6
  timestamp: 1758819821241,
7
  payload: {
8
    job: {
9
      _id: '50329d1bc0594165b5b1825a',
10
      name: 'slaBreach',
11
      tasks: {
12
        '1132': {
13
          name: 'delay',
14
          canvasName: 'delay',
15
          summary: 'Delay a Job',
16
          description: 'Delay a Job for a duration by Job ID and number of seconds.',
17
          location: 'Application',
18
          locationType: null,
19
          app: 'WorkFlowEngine',
20
          type: 'operation',
21
          displayName: 'WorkFlowEngine',
22
          variables: {
23
            incoming: { time: null },
24
            outgoing: { time_in_milliseconds: '' },
25
            decorators: []
26
          },
27
          actor: 'Pronghorn',
28
          groups: [],
29
          nodeLocation: { x: 24, y: -84 },
30
          status: 'complete',
31
          previous: { incomplete: [], complete: [], error: [] },
32
          incomingRefs: [
33
            {
34
              type: 'static',
35
              pointer: '/variables/incoming/time',
36
              reference: { location: 'document', value: 2 }
37
            }
38
          ],
39
          outgoingRefs: [
40
            {
41
              type: 'taskOutgoing',
42
              status: 'success',
43
              pointer: '/variables/outgoing/time_in_milliseconds',
44
              taskVariableName: 'time_in_milliseconds'
45
            },
46
            {
47
              type: 'taskOutgoing',
48
              status: 'error',
49
              pointer: '/variables/error',
50
              taskVariableName: null
51
            }
52
          ],
53
          taskId: '1132',
54
          owner: 'Pronghorn',
55
          iterations: [ '440c69a5-e38b-495d-a0a2-00363f924fc1' ],
56
          transitions: { success: [ { task: 'workflow_end', type: 'standard' } ] },
57
          serverId: 'local_node1',
58
          start_time: '2025-09-25T17:03:38.957Z',
59
          end_time: 1758819820979,
60
          finish_state: 'success'
61
        },
62
        workflow_start: {
63
          name: 'workflow_start',
64
          groups: [],
65
          nodeLocation: { x: 0, y: -500 },
66
          x: 0,
67
          y: 0.5,
68
          status: 'complete',
69
          metrics: {
70
            start_time: 1758819818925,
71
            user: '667afeda7cd7b76286c0bfb5',
72
            finish_state: 'success'
73
          },
74
          taskId: 'workflow_start',
75
          owner: 'Pronghorn',
76
          iterations: [],
77
          transitions: { success: [ { task: '1132', type: 'standard' } ] }
78
        },
79
        workflow_end: {
80
          name: 'workflow_end',
81
          groups: [],
82
          nodeLocation: { x: 0, y: 500 },
83
          x: 1,
84
          y: 0.5,
85
          status: 'complete',
86
          previous: { incomplete: [], complete: [ '1132' ], error: [] },
87
          taskId: 'workflow_end',
88
          owner: 'Pronghorn',
89
          iterations: [],
90
          transitions: {},
91
          endTasks: { incomplete: [], complete: [], error: [] },
92
          metrics: { end_time: 1758819821011, run_time: 2086 }
93
        }
94
      },
95
      transitions: {
96
        '1132': { workflow_end: { state: 'success', type: 'standard' } },
97
        workflow_start: { '1132': { state: 'success', type: 'standard' } },
98
        workflow_end: {}
99
      },
100
      canvasVersion: 3,
101
      type: 'automation',
102
      font_size: 12,
103
      errorHandler: null,
104
      preAutomationTime: 0,
105
      sla: 1000,
106
      groups: [ 'default' ],
107
      last_updated: '2025-09-25T17:03:41.008Z',
108
      lastUpdatedVersion: '5.55.5',
109
      uuid: '82cbd255-86aa-4fc1-b403-6cc3a20e0986',
110
      created: '2025-09-25T17:03:10.090Z',
111
      created_by: '667afeda7cd7b76286c0bfb5',
112
      createdVersion: '5.55.5',
113
      encodingVersion: 1,
114
      last_updated_by: '667afeda7cd7b76286c0bfb5',
115
      description: '',
116
      status: 'complete',
117
      variables: {
118
        _id: { location: 'job_data', _id: '68d575ea51431df6af6c7e4e' },
119
        initiator: { location: 'job_data', _id: '68d575ea51431df6af6c7e4f' }
120
      },
121
      watchers: [ '667afeda7cd7b76286c0bfb5' ],
122
      ancestors: [ '50329d1bc0594165b5b1825a' ],
123
      mocked: false,
124
      decorators: [],
125
      metrics: {
126
        start_time: 1758819818925,
127
        user: '667afeda7cd7b76286c0bfb5',
128
        progress: 1,
129
        end_time: 1758819821011
130
      }
131
    },
132
    runTime: 2086,
133
    slaDelta: 1086
134
  }
135
}
