Configuring OpenLDAP

Use the following to set-up OpenLDAP with adapter-ldap for the Itential Automation Platform (IAP).

Note: For documentation purposes, the following steps were executed from a CentOS 7 install.

Install OpenLDAP

To install and configure OpenLDAP:

1. Install openldap.

   yum install -y openldap openldap-clients openldap-servers


2. Encrypt the password for the admin.

   [root@localhost cn=config]# slappasswd
   New password:
   Re-enter new password:
   {SSHA}HPHUXuZhbtOs0CIRhnWjglbitrlWt0Lh


3. Edit the olcDatabase\=\{2\}hdb.ldif file.

   vi /etc/openldap/slapd.d/cn=config/olcDatabase\=\{2\}hdb.ldif


4. Modify the attributes. Remember to replace the value for olcRootPW with the encrypted value of your unique password provided by the slappasswd command.

   olcSuffix: dc=pronghorn,dc=io
   olcRootDN: cn=admin,dc=pronghorn,dc=io
   olcRootPW: {SSHA}HPHUXuZhbtOs0CIRhnWjglbitrlWt0Lh


5. Edit the olcDatabase={1}monitor.ldif file.

   vi /etc/openldap/slapd.d/cn=config/olcDatabase={1}monitor.ldif


6. Modify the access entry by deleting the existing line and replacing it with the following command.

   olcAccess: {0}to * by dn.base="gidNumber=0+uidNumber=0,cn=peercred,cn=external, cn=auth" read by dn.base="cn=admin,dc=pronghorn,dc=io" read by * none


7. Validate the configuration. The checksum errors on the two files modified in Step 3 and Step 5 are expected.

   [root@localhost vagrant]# slaptest -u
   5a9d88af ldif_read_file: checksum error on "/etc/openldap/slapd.d/cn=config/olcDatabase={1}monitor.ldif"
   5a9d88af ldif_read_file: checksum error on "/etc/openldap/slapd.d/cn=config/olcDatabase={2}hdb.ldif"
   config file testing succeeded


8. Copy the DB_CONFIG file for OpenLDAP.

   ls -l /var/lib/ldap/DB_CONFIG
   cp /usr/share/openldap-servers/DB_CONFIG.example /var/lib/ldap/DB_CONFIG
   chown -R ldap:ldap /var/lib/ldap/


9. Restart openldap.

   systemctl enable slapd
   service slapd restart


10. Add standard OpenLDAP schemas.

    ldapadd -Y EXTERNAL -H ldapi:/// -f /etc/openldap/schema/cosine.ldif
    ldapadd -Y EXTERNAL -H ldapi:/// -f /etc/openldap/schema/inetorgperson.ldif


11. Add the memberof OpenLDAP schema.

    Note: For any steps that create an LDIF file, you may need to break the commands down into smaller chunks as illustrated below.

    cat << EOF > /etc/openldap/schema/memberof.ldif
    dn: cn=module,cn=config
    cn: module
    objectclass: olcModuleList
    objectclass: top
    olcmoduleload: memberof.la
    olcmodulepath: /usr/lib64/openldap
    EOF

    cat << EOF > /etc/openldap/schema/enable-memberof.ldif
    dn: olcOverlay={0}memberof,olcDatabase={2}hdb,cn=config
    objectClass: olcConfig
    objectClass: olcMemberOf
    objectClass: olcOverlayConfig
    objectClass: top
    olcOverlay: memberof
    EOF

    cat << EOF > /etc/openldap/schema/refint.ldif
    dn: cn=module,cn=config
    cn: module
    objectclass: olcModuleList
    objectclass: top
    olcmoduleload: refint.la
    olcmodulepath: /usr/lib64/openldap
    EOF

    cat << EOF > /etc/openldap/schema/enable-refint.ldif
    dn: olcOverlay={1}refint,olcDatabase={2}hdb,cn=config
    objectClass: olcConfig
    objectClass: olcOverlayConfig
    objectClass: olcRefintConfig
    objectClass: top
    olcOverlay: {1}refint
    olcRefintAttribute: memberof member manager owner
    EOF


12. Import the following schema files (in order).

    ldapadd -Y EXTERNAL -H ldapi:/// -f /etc/openldap/schema/memberof.ldif
    ldapadd -Y EXTERNAL -H ldapi:/// -f /etc/openldap/schema/enable-memberof.ldif
    ldapadd -Y EXTERNAL -H ldapi:/// -f /etc/openldap/schema/refint.ldif
    ldapadd -Y EXTERNAL -H ldapi:/// -f /etc/openldap/schema/enable-refint.ldif


13. Add the OpenLDAP schema to create users and group nodes. This is a custom LDIF to create users and group organizational units, and the default admin user.

    • Replace the userPassword component of the Itential admin user with a value obtained by running the slappasswd utility.
    • Once the ldapadd command is executed, you will be prompted for a password. Enter the OpenLDAP admin password created in Step 2.

    cat << EOF > /etc/openldap/schema/pronghorn.ldif
    dn: dc=pronghorn,dc=io
    objectclass: domain
    dc: pronghorn

    dn: ou=users,dc=pronghorn,dc=io
    description: pronghorn users
    objectclass: organizationalUnit
    ou: users

    dn: ou=groups,dc=pronghorn,dc=io
    description: pronghorn groups
    objectclass: organizationalUnit
    ou: groups

    dn: uid=admin@pronghorn,ou=users,dc=pronghorn,dc=io
    uid: admin@pronghorn
    objectClass: inetOrgPerson
    cn: admin
    sn: admin
    mail: nobody@pronghorn.io
    userPassword: {SSHA}qPe2L+D5288ikfEXttx0hLr8hQIunHo+
    EOF


14. Import the schema.

    ldapadd -c -x -W -D "cn=admin,dc=pronghorn,dc=io" -f /etc/openldap/schema/pronghorn.ldif
    Enter LDAP Password:
    adding new entry "dc=pronghorn,dc=io"
    adding new entry "ou=users,dc=pronghorn,dc=io"
    adding new entry "ou=groups,dc=pronghorn,dc=io"
    adding new entry "uid=admin@pronghorn,ou=users,dc=pronghorn,dc=io"


15. Use Apache Directory Studio to connect to the LDAP server.

16. Verify the connect and credentials are running as expected.

Create Groups and Users in OpenLDAP

Each group object should be created as a groupOfUniqueNames with its common name (cn) containing the name of the group.

If the group object is some other class (i.e. groupOfNames), the groupSearchFilter in the LDAP adapter properties must be aligned with the class (i.e. objectClass=groupOfNames).

Use the sample LDIF files to creates users and groups.

1. Create the following groups in OpenLDAP.

   Group	Description
   global_admin	Multi-Tenant Administrator Group
   global_ops	Multi-Tenant Operations Group
   tenant1_admin	Tenant1 Administrator Group
   tenant1_ops	Tenant1 Operations Group
   tenant2_admin	Tenant2 Administrator Group
   tenant2_ops	Tenant2 Operations Group

2. Create the following users in OpenLDAP.

   User	First Name	Last Name	Email	Groups
   global@admin	admin	global	nobody@itential.io	global_admin
   global@ops	ops	global	nobody@itential.io	global_ops
   tenant1@admin	admin	tenant1	nobody@itential.io	tenant1_admin
   tenant1@ops	ops	tenant1	nobody@itential.io	tenant1_ops
   tenant2@admin	admin	tenant2	nobody@itential.io	tenant2_admin
   tenant2@ops	ops	tenant2	nobody@itential.io	tenant2_ops

3. Adjust the users, passwords, and groups in the sample files (if needed).

4. Create the tenant-users.ldif file.

   cat << EOF > /etc/openldap/schema/tenant-users.ldif
   dn: uid=admin@global,ou=users,dc=pronghorn,dc=io
   uid: admin@global
   objectClass: inetOrgPerson
   cn: admin
   sn: global
   mail: nobody@pronghorn.io
   userPassword: {SSHA}qPe2L+D5288ikfEXttx0hLr8hQIunHo+

   dn: uid=admin@tenant1,ou=users,dc=pronghorn,dc=io
   uid: admin@tenant1
   objectClass: inetOrgPerson
   cn: admin
   sn: tenant1
   mail: nobody@pronghorn.io
   userPassword: {SSHA}qPe2L+D5288ikfEXttx0hLr8hQIunHo+

   dn: uid=admin@tenant2,ou=users,dc=pronghorn,dc=io
   uid: admin@tenant2
   objectClass: inetOrgPerson
   cn: admin
   sn: tenant2
   mail: nobody@pronghorn.io
   userPassword: {SSHA}qPe2L+D5288ikfEXttx0hLr8hQIunHo+

   dn: uid=ops@global,ou=users,dc=pronghorn,dc=io
   uid: ops@global
   objectClass: inetOrgPerson
   cn: ops
   sn: global
   mail: nobody@pronghorn.io
   userPassword: {SSHA}qPe2L+D5288ikfEXttx0hLr8hQIunHo+

   dn: uid=ops@tenant1,ou=users,dc=pronghorn,dc=io
   uid: ops@tenant1
   objectClass: inetOrgPerson
   cn: ops
   sn: tenant1
   mail: nobody@pronghorn.io
   userPassword: {SSHA}qPe2L+D5288ikfEXttx0hLr8hQIunHo+

   dn: uid=ops@tenant2,ou=users,dc=pronghorn,dc=io
   uid: ops@tenant2
   objectClass: inetOrgPerson
   cn: ops
   sn: tenant2
   mail: nobody@pronghorn.io
   userPassword: {SSHA}qPe2L+D5288ikfEXttx0hLr8hQIunHo+
   EOF


5. Import the tenant-users.ldif file.

   ldapadd -c -x -W -D "cn=admin,dc=pronghorn,dc=io" -f /etc/openldap/schema/tenant-users.ldif


6. Create the tenant-groups.ldif file.

   cat << EOF > /etc/openldap/schema/tenant-groups.ldif
   dn: cn=pronghorn_admin,ou=groups,dc=pronghorn,dc=io
   objectClass: groupOfNames
   cn: pronghorn_admin
   member: uid=admin@pronghorn,ou=users,dc=pronghorn,dc=io

   dn: cn=global_admin,ou=groups,dc=pronghorn,dc=io
   objectClass: groupOfNames
   cn: global_admin
   member: uid=admin@global,ou=users,dc=pronghorn,dc=io

   dn: cn=global_ops,ou=groups,dc=pronghorn,dc=io
   objectClass: groupOfNames
   cn: global_ops
   member: uid=ops@global,ou=users,dc=pronghorn,dc=io

   dn: cn=tenant1_admin,ou=groups,dc=pronghorn,dc=io
   objectClass: groupOfNames
   cn: tenant1_admin
   member: uid=admin@tenant1,ou=users,dc=pronghorn,dc=io

   dn: cn=tenant1_ops,ou=groups,dc=pronghorn,dc=io
   objectClass: groupOfNames
   cn: tenant1_ops
   member: uid=ops@tenant1,ou=users,dc=pronghorn,dc=io

   dn: cn=tenant2_admin,ou=groups,dc=pronghorn,dc=io
   objectClass: groupOfNames
   cn: tenant2_admin
   member: uid=admin@tenant2,ou=users,dc=pronghorn,dc=io

   dn: cn=tenant2_ops,ou=groups,dc=pronghorn,dc=io
   objectClass: groupOfNames
   cn: tenant2_ops
   member: uid=ops@tenant2,ou=users,dc=pronghorn,dc=io
   EOF


7. Import the tenant-groups.ldif file.

   ldapadd -c -x -W -D "cn=admin,dc=pronghorn,dc=io" -f /etc/openldap/schema/tenant-groups.ldif


OpenLDAP Configuration Example

The following is an example for OpenLDAP configuration. The hostname in the URL must match the common name of the LDAP server certificate.

{
    "id": "ldap",
    "type": "LDAP",
    "properties": {
        "domain":  "uid={0},ou=users,dc=pronghorn,dc=io",
        "url": "ldaps://example.pronghorn.io:636",
        "bindUsername": "cn=admin,dc=pronghorn,dc=io",
        "bindPassword": "<your_user_password>",
        "baseDN": "dc=pronghorn,dc=io",
        "baseGroupDN": "ou=groups,dc=pronghorn,dc=io",
        "baseUserDN": "ou=users,dc=pronghorn,dc=io",
        "groupSearchFilter": "(objectClass=groupOfNames)",
        "userSearchFilter": "uid",
        "userMembershipAttribute": "memberOf",
        "healthCheckInterval": 5000,
        "timeout": 5000,
        "connectTimeout": 5000,
        "idleTimeout": 5000,
        "timeLimit": 10,
        "reconnect": true,
        "activeDirectory": false,
        "tlsOptions": {
            "secureProtocol": "TLSv1_method",
            "requestCert": true,
            "rejectUnauthorized": true,
            "ca": "/etc/ssl/keys/openldap_ca.pem"
} },
    "brokers": [ "aaa" ]
}
